OKW DIN rail enclosures

Click2Contact

For industrial and automated systems, it is important to be able to install devices easily. OKW’s DIN rail enclosures are designed to bring structure to the control cabinet, as the electronic components are clearly arranged and easily accessible, thereby improving safety and reducing maintenance.

OKW offers DIN rail enclosures for TH35, TH15 and G32 rails in modular widths from 1 to 12 units.

The RAILTEC B enclosure family is characterised by its simple and fast snap-in installation on DIN rails complying with EN 60715 TH35. Available in six sizes (2–12 modules) based on DIN 43880, size 1, the enclosures have a modular design and are offered in various versions suitable for terminal blocks, plug headers, front connectors and D-Sub connectors. They can be installed as complete enclosures or as open enclosures for individual configurations (terminal covers, partitions, front panels, etc.). The enclosures are also available either with or without ventilation slots to improve heat dissipation.

The panel-mounted variant RAILTEC BP, M22 is notable for its simple and flexible assembly, featuring screwless enclosure mounting. As an accessory for this version, a transparent, hinged cover is available to provide added protection for integrated display and control elements while providing a clear view of the applications.

The RAILTEC C product group has a similar structure (adapters are also available as accessories for TH15 and G32) but is also suitable for direct wall mounting. This range includes modular subrack systems — RAILTEC SUPPORT — which allow for individual assembly and offer greater flexibility through the replacement of interfaces.

DIN rail enclosures are suitable for applications in Industry 4.0, smart factories, enclosure and safety technology, automation, heating/air conditioning/environmental technology, lighting control, sensors and much more.

Standard enclosures can also be adapted to specific requirements through customised modifications. Various options are available, including mechanical processing, painting, printing, laser marking and decorative foils, as well as assembly and packaging.
