Silver-based films for flexible screens

Danish researchers have demonstrated the large-scale fabrication of a new type of transparent conductive electrode film based on nanopatterned silver, offering a high-performance and long-lasting option for use with flexible screens and electronics.

Smartphone touch screens and flat panel televisions use transparent electrodes to detect touch and to quickly switch the colour of each pixel. Most of today’s transparent electrodes are made of indium tin oxide (ITO), which can exhibit up to 92% transparency — comparable to glass. Although highly transparent, ITO thin films must be processed carefully to achieve reproducible performance and are too brittle to use with flexible electronics or displays. Researchers are seeking alternatives to ITO because of these drawbacks.

The anti-corrosive nature of noble metals such as gold, silver and platinum makes them promising ITO alternatives for creating long-lasting, chemically resistant electrodes that could be used with flexible substrates. However, until now, noble metal transparent conductive films have suffered from high surface roughness, which can degrade performance because the interface between the film and other layers isn’t flat. Transparent conductive films can also be made using carbon nanotubes, but these films don’t currently exhibit high enough conductance for all applications and tend to also suffer from surface roughness due to the nanotubes stacking on top of each other.

Now, researchers from the University of Southern Denmark have used an approach called colloidal lithography to create transparent conductive silver thin films. They first created a masking layer, or template, by coating a 10 cm wafer with a single layer of evenly sized, close-packed plastic nanoparticles. The researchers placed these coated wafers into a plasma oven to shrink the size of all the particles evenly. When they deposited a thin film of silver onto the masking layer, the silver entered the spaces between the particles. They then dissolved the particles, leaving a precise pattern of honeycomb-like holes that allow light to pass through, producing an electrically conductive and optically transparent film.

“The approach we used for fabrication is highly reproducible and creates a chemically stable configuration with a tuneable trade-off between transparency and conductive properties,” said Jes Linnet, first author on the study. “This means that if a device needs higher transparency but less conductivity, the film can be made to accommodate by changing the thickness of the film.”

Writing in the journal Optical Materials Express, the researchers revealed that their large-scale fabrication method can be used to create silver transparent electrodes with as much as 80% transmittance while keeping electrical sheet resistance below 10Ω per square — about a tenth of what has been reported for carbon-nanotube-based films with the equivalent transparency. The lower the electrical resistance, the better the electrodes are at conducting an electrical charge.

“The most novel aspect of our work is that we accounted for both the transmission properties and the conductance properties of this thin film using theoretical analysis that correlated well with measured results,” said Linnet. “Fabrication problems typically make it hard to get the best theoretical performance from a new material. We decided to report what we encountered experimentally and postulate remedies so that this information could be used in the future to avoid or minimise problems that may affect performance.”

The researchers say that their findings show that colloidal lithography can be used to fabricate transparent conductive thin films that are chemically stable and could be useful for a variety of applications, including flexible screens and electronics. The silver-based films could also enable flexible solar cells for installation on windows, roofs and even personal devices.
