Novel method to get efficient, environmentally friendly lithium


By Sarah C.P. Williams, The UChicago Pritzker School of Molecular Engineering
Thursday, 27 June, 2024


Novel method to get efficient, environmentally friendly lithium

As the electric vehicle market booms, the demand for lithium — the mineral required for lithium-ion batteries — has also soared. Global lithium production has more than tripled in the last decade.

But current methods of extracting lithium from rock ores or brines are slow and come with high energy demands and environmental costs. They also require sources of lithium which are incredibly concentrated to begin with and are only found in a few countries.

Now, researchers at the University of Chicago Pritzker School of Molecular Engineering (PME) have optimised a new method for extracting lithium from more dilute — and widespread — sources of the mineral, including seawater, groundwater and “flowback water” left behind from fracking and offshore oil drilling.

“Right now there is a gap between the demand for lithium and the production,” said Chong Liu, Neubauer Family Assistant Professor of Molecular Engineering and senior author of the new work, published in Nature Communications. “Our method allows the efficient extraction of the mineral from very dilute liquids, which can greatly broaden the potential sources of lithium.”

In the new research, Liu and her colleagues showed how certain particles of iron phosphate can most efficiently pull lithium out of dilute liquids. Their new findings could hasten an era of faster, greener lithium extraction.

Lithium at a cost

Today, most lithium used in lithium batteries comes from two basic extraction processes. Lithium rock ores can be mined, smashed up with heavy machinery, and then treated with acid to isolate the lithium. Lithium brine pools, on the other hand, use massive amounts of water pumped to the Earth’s surface and then evaporated away — over the course of more than a year — to yield dried lithium.

“These methods aren’t particularly environmentally friendly to begin with, and if you start trying to work with less concentrated sources of lithium, they’re going to become even less efficient,” Liu said. “If you have a brine that is 10 times more dilute, you need 10 times more briny water to get the same amount of lithium.”

In recent years, Liu’s team has spearheaded a completely different method to get lithium out of dilute liquids. Their approach isolates lithium based on its electrochemical properties, using crystal lattices of olivine iron phosphate. Because of its size, charge and reactivity, lithium is drawn into the spaces in the olivine iron phosphate columns — like water being soaked into the holes in a sponge. But, if the column is designed perfectly, sodium ions, also present in briny liquids, are left out or enter the iron phosphate at a much lower level.

In the new work, Liu and her colleagues, including first author of the new paper Gangbin Yan, a PME graduate student, tested how variation in olivine iron phosphate particles impacted their ability to selectively isolate lithium over sodium.

“When you produce iron phosphate, you can get particles that are drastically different sizes and shapes,” Yan explained. “In order to figure out the best synthesis method, we need to know which of those particles are most efficient at selecting lithium over sodium.”

Not too big, not too small

The research team synthesised olivine iron phosphate particles using different methods, resulting in a range of particle sizes spanning 20 to 6000 nanometres. Then, they divided those particles into groups based on their size and used them to build electrodes that could extract lithium from a weak solution.

When iron phosphate particles were too large or too small, they discovered, they tended to let more sodium into their structures. That led to less pure extractions of lithium.

“It turned out that there was this sweet spot in the middle where both the kinetics and the thermodynamics favour lithium over sodium,” Liu said.

The findings are vital to moving electrochemical lithium extraction towards commercial use. They suggest that researchers should focus on not just producing olivine iron phosphate, but producing olivine iron phosphate at the ideal particle size.

“We have to keep this desired particle size in mind as we pick synthesis methods to scale up,” Liu said. “But if we can do this, we think we can develop a method that reduces the environmental impact of lithium production and secures the lithium supply in this country.”

Image caption: In a new study, UChicago Pritzker Molecular Engineering Asst. Prof. Chong Liu (right), PhD student and first author Gangbin Yan (left), and co-authors optimised a new method for extracting lithium from more dilute and widespread sources. Image credit: John Zich/ The UChicago Pritzker School of Molecular Engineering.
