Novel approach to control ferroelectricity in perovskites
Researchers from Nagoya University have synthesised four- and five-layered versions of perovskite. Analysing the mechanism of ferroelectricity in the material, they found that perovskite switches its ferroelectric mechanisms depending on whether the number of layers is odd or even. Researchers expect that these diverse properties will expand the development of new electronic devices.
Perovskites are a class of materials that share a specific crystal structure made up of calcium titanium oxides. Electronic devices often use perovskites because they exhibit a property called ferroelectricity. Ferroelectricity allows for the control and reversal of electric polarisation by an external electric field. This feature makes perovskites useful for electronic devices such as memory, capacitors, actuators and sensor devices, which use on and off states.
To improve functionality and reduce the environmental impact of these products, researchers are developing new compositions, structures and lead-free ferroelectrics. Perovskites, especially Dion-Jacobson (DF)-type layered perovskites, are becoming an important class of materials in this research.
DJ-type perovskites have a layered octahedral structure, which makes the layers asymmetrical, giving them ferroelectric properties. The ferroelectric properties are caused by the shifting of positive and negative ions when an outside field is applied, causing rotation and tilting of the octahedra due to size mismatches. This tilting lowers the symmetry of the material, further contributing to ferroelectric behaviour.
Minoru Osada, a researcher from Nagoya University, said the researchers considered layered perovskites unexplored materials due to the decline in thermodynamic stability as the thickness of the perovskite layers increases. To overcome this, the researchers developed a new method, known as the template synthesis method, that enables the synthesis of multilayer structures by layering perovskite layers one by one and aligning their octahedrons like building blocks.
“In the template synthesis method, the number of layers can be increased by one layer by using a three-layer system as the starting material and reacting it with SrTiO3. By repeating the reaction, the number of perovskite layers can be digitally controlled according to the number of reactions, allowing the synthesis of a multilayer structure. By applying the template synthesis method, we synthesised four- and five-layered perovskites for the first time,” Osada said.
When the researchers tested the material, they found that it behaved strangely, exhibiting different dielectric constants and Curie temperature depending on the number of layers.
“We found that the number of layers plays an important role in this system, and that it has a unique function to switch to the conventional direct ferroelectricity model when the number of layers is odd and to the new indirect ferroelectricity model when the number is even,” Osada said.
This approach provides a new opportunity to expand the range of ferroelectric materials beyond the thermodynamically stable phases. This achievement could expand the material search space in the development of ferroelectrics and provide important guidelines for the development of new materials and functions that are difficult to realise with existing materials and technologies.
The research findings were published in the Journal of the American Chemical Society.
