Novel material improves stability, efficiency of PSCs
A team of chemists from Kaunas University of Technology (KTU), in Lithuania, has developed a new material for perovskite solar cells.
After polymerisation, it can be used as a hole transporting layer in both regular and inverted architecture solar cells; in both cases, the solar elements constructed have better power conversion efficiencies and operational stability.
Perovskite solar cells (PSCs) have received significant interest from the photovoltaic community due to their skyrocketing power conversion. Moreover, PSCs may be scaled up using a low-cost production process from widely available abundant raw materials. These aspects show promise for PSCs as a future mainstream photovoltaic technology. However, the long-term stability of perovskite solar devices under practical working conditions still requires further improvement to satisfy market demands.
A novel 9.9′-spirobifluorene derivative bearing thermally cross-linkable vinyl groups, synthesised by the team of chemists at KTU, could help solve some of the abovementioned challenges. After thermal cross-linking, a smooth and solvent-resistant three-dimensional (3D) polymeric network is formed, which was used as a hole-transporting material to construct perovskite solar cells.
“The copolymerisation takes place at a relatively low temperature (103°C), which makes the technology safe for use in the casting of a layer on perovskite, which is not resistant to temperatures above 140°C. Another very important aspect is that the polymerisation process is incredibly fast, apparently due to the specific spatial configuration of the monomer,” said Šarunė Daškevičiūtė-Gegužienė, one of the authors of the invention, and a PhD student at the KTU Faculty of Chemical Technology.
The resulting devices exhibited better energy conversion efficiency and, most importantly, stability than conventional hole transporting materials (PTAA or Spiro-OMeTAD).
High commercialisation possibilities, patent pending
Layered perovskite solar cells (new generation solar cells) can have two architectonic structures — regular (n-i-p) and inverted (p-i-n). In the latter, the hole transporting materials are deposited under the perovskite absorber layer.
The monomer, synthesised at KTU laboratories, easily produces solvent-resistant three-dimensional (3D) polymers that can be used in both types of perovskite solar cells.
“Polymer synthesis is carried out by heating the monomer layers for as little as 15 min, yielding spatially structured insoluble polymer matrices,” said Professor Vytautas Getautis, the Lead Researcher at the Synthesis of Organic Semiconductors research group, at KTU.
To date, the best performances of conventional structure (n-i-p) perovskite solar cells have been achieved with the well-studied p-type semiconductor Spiro-OMeTAD. However, the latter has not found application in inverted structure (p-i-n) devices due to its solubility, as the polar solvents used in the moulding of the perovskite layer dissolve the hole transporting layer below.
The 9.9′-spirobifluorene derivative synthesised at KTU laboratories yields a cross-linked organic solvent-resistant polymer layer. Meanwhile, a copolymer of the 9.9′-spirobifluorene derivative with a dithiol (eg, 4.4′-thiobisbenzenethiol), formed on the perovskite layer in the construction of (n-i-p)-structured devices, protects it from external unwanted influences such as humidity.
According to researchers, the novel synthesised material has high commercialisation potential; therefore, the patent application was filed at the EU, USA and Japanese patent offices.
Cooperation between Lithuanian and Japanese scientists
The researchers emphasise that the results achieved are the product of successful collaboration between Lithuanian and Japanese scientists.
“For several years now, our research group has been collaborating with that of Professor Atsushi Wakamiya’s at Kyoto University, which is well known among perovskite solar cell researchers not only in Japan, but also worldwide. It was they who designed and characterised perovskite solar cells using our synthesised p-type organic semiconductors,” Getautis said.
The electrical properties of these semiconductors have been investigated by KTU chemists’ long-time partner Professor Vygintas Jankauskas from Vilnius University.
The KTU research group under the lead of Professor Getautis is responsible for numerous innovations in solar technology field. Among them are synthesised compounds, which self-assemble into a molecule-thin layer that acts as a hole transporting material, which has been used to construct record-breaking silicone-perovskite tandem solar cells.
According to Professor Getautis, of all renewables, solar energy has the largest potential and is the least exploited. However, thanks to the new research, this field is developing exponentially. It is estimated that by 2050, around half of the electricity used on earth will be produced from solar energy.
“Solar energy is entirely green — it is pollution-free, and the installed solar farms don’t require much maintenance. Keeping in mind current events, and the energy crisis, more and more people are interested in installing solar power plants in their homes or owning a share of a solar farm. It is a future of energy,” Getautis said.
The research findings were published in the journal Applied Materials & Interfaces.
